ElectroDroid is a straightforward and sturdy series of electronics instruments and references.
Right here’s the free model, which contains adverts; that you just may also additionally accumulate from the Market the PRO model of the app to red meat up the developer, free up more choices and rep rid of the adverts.
The app consists of:
• Resistor color code decoder (3-6 bands);
• SMD Resistor Code;
• Inductor color code decoder;
• Ohm’s law calculator;
• Reactance/Resonance calculator;
• Voltage divider;
• Resistors ratio, cost/sequence/parallel;
• Capacitor cost calculation;
• Operational amplifier;
• LED resistor calculator;
• Adjustable voltage regulator/LM317 calculator;
• Heat dissipation;
• Battery Existence calculator;
• Inductor create tool;
• Voltage Tumble calculator;
• PCB Hint Width calculator;
• Easy Filters calculator;
• NE555 calculator;
• Vitality Calculator;
• Decibel Converter;
• Frequency Converter;
• Analog-Digital Converter;
• Y-Δ Transformation;
• Port pin-out (USB, Serial, Parallel, Ethernet, RJ, SCART, DVI, HDMI, S-Video, VGA, VESA, Give an explanation for Port, FireWire, Jack, RCA, Audio DIN connector, XLR/DMX, ATX Vitality, PC peripheral connectors, EIDE/ATA, SATA, PS/2-AT, MIDI/Sport port, Apple 30-pin, Apple Lightning connector, PDMI, OBD-II, 25-pair phone cable color code, Color Code for Fiber Optic Cables, MIDI connector, ISO connector for car audio, Arduino pin-outs);
• Sources (USB specification, Resistivity desk, Table of now not unusual resistors and capacitors, Capacitor marking codes, AWG and SWG Wire dimension, Ampacity Table, Symbols and Abbreviations, Circuit Schematic Symbols, SI Devices prefixes, Battery recordsdata, Boolean common sense gate and algebra Theorems, 7400 recordsdata and pinout, ASCII codes, Batteries list, Coin Batteries, 78xx IC, ChipDB IC pinouts, Switch Knowledge, Decibel Table, PIC ICSP/AVR ISP, SMD Equipment Dimension, Radio frequencies);
• Beefy red meat up for EIA resistor sequence for all calculators;
…and more to reach wait on!
The app has also red meat up for plugins to broaden functionality of the utility (e.g. PIC and AVR micro-controllers Database, simulators, sides search).
Whilst you occur to adore the program, please fee it, and accumulate the total model to red meat up the pattern.
Electrodroid PRO link: play.google.com/store/apps/minute print?identification=it.android.demi.elettronica.professional
For FAQ and full alternate-log, test with electrodroid.it
The Android robot in the set up is modified from work created and shared by Google and used in accordance with phrases described in the CC BY 3.0 License.
Version 4.9:
• novel resources: Raspberry Pi4, USB 3.2 specification;
• up so some distance varied resources;
• desk headers fixed at the highest;
• up so some distance deprecated Google libraries;
• bugs fix and varied enhancements;
• translation updates;
